HOWO NX 8×4 Fuel tank truck

HOWO NX 8×4 Fuel Tanker Truck is equipped with SINOTRUK 8×4 heavy-duty reinforced chassis with four-axle reasonable layout and uniform axle load distribution, stronger load capacity, larger tank volume and higher transportation efficiency, which is the first choice for large oil depots and long-distance fuel transportation.
Contact Us

◉ Product Introduction

HOWO NX 8×4 Fuel Tanker Truck is equipped with SINOTRUK 8×4 heavy-duty reinforced chassis with four-axle reasonable layout and uniform axle load distribution, stronger load capacity, larger tank volume and higher transportation efficiency, which is the first choice for large oil depots and long-distance fuel transportation.


The drive axle adopts multi-axle heavy-duty structure with extremely high strength and outstanding stability.

The engine adopts large-displacement and high-torque power with sufficient reserve, strong climbing ability and high durability. Based on safety and efficiency, the vehicle escorts global energy transportation with SINOTRUK’s top manufacturing strength.


Configuration sheet


Model:ZZ1317V466JB1

CHASSIS SPECS

Drive style

Left hand drive

Engine:

WD615.47, 371HP, with EURO 2 engine emission, 9.726L, 6 cylinders In-line

Transmission:

HW19710+HW50direct-drivePTO;(10 forward 2 reverse)

Cabin:

Howo H77L Cab, with A/C

Color:

White

Wheelbase:

4600mm

Tire:

11.00R20/12.00R20/315/80R22.5 tyres(12+1)

Front axle:

9.5T(drum)

Rear axle:

16T(drum)

Capacity of oil tank:

400L

Others

Power steer,Exhaust brake and spring brake

CARRIAGE BODY SPECS

Tank volume:

20-30 cubic meters

Tank thickness:

5mm

End cap thickness:

5mm

Baffle thickness:

3mm

Others:

Equipped with a gear oil pump, pressure relief system, gravity flow system, fireproof cap, fire extinguisher, bottom valve, and two drain hoses.

Package

Wax


◉ Product Details

  • 4a8ae748-5672-4993-987b-373f9a231791
  • 093fc98b-f700-48b9-8706-60878612f3a2
  • 8b990c24-aea4-4b26-817a-b7603e5032d4
  • 747ee0e4-bd95-4472-b68e-7c3bbbfddb42
  • bc595f1d-502d-439e-b023-21d856eb91d0
  • df8f86ca-1b1e-475f-958c-aae986e54074

◉ Shipping

  • 820f9cfa-ed85-4f6d-b0b8-21fd9a22035a
  • fe67c6cf-6bb8-44e6-97e4-efccf43be49b
  • 1297376.jpg_1200xx.nw
  • 1338314.jpg_1200xx.nw
  • 1297375.jpg_1200xx.nw
  • 6092cc4a-801d-4d97-a25f-881ddac61776
